PA bass speaker and subwoofer, 20cm, 300W MAX, 8 Ohm
Code: MZMSP8150PRO
£62.77
(£52.31
ex VAT)
Quantity Pricing
2
-
4
£62.32
each
(£51.93
each ex VAT)
5
+
£61.85
each
(£51.54
each ex VAT)
Choose quantity
Order now for dispatch on Wed 7th Jan.
Description
Compact professional PA bass speaker, subwoofer, 300WMAX, 150WRMS 8 Ω, 20cm (8")
This PA bass speaker is of long excursion and high power capability, with diecast aluminium basket, rear-ventilated centering spider and ventilated drive system for a high thermal stability. It features ideal parameters for a very good bass reproduction in compact bass-reflex cabinets.
This exceptional speaker from the L-RAY bass module combines a high power capability, a good efficiency and an amazing mechanical stability in a format which at 20cm is of extra compact size. This makes it a real bass speaker for the limit frequencies which normally require 30cm (12") PA speakers.
- 20 cm (8") bass speaker and subwoofer of high power capability
- Heat-resistant voice coil and ventilated drive system
- Drive configuration of very long excursion for a deep bass reproduction of high volumes
- Progressive cone suspension for a high operating reliability
- Robust diecast aluminium basket
- Ideally suited for 2-way systems and compact subwoofers
IMG STAGE LINE product code: SP-8/150PRO
Details
TECHNICAL DATA:
| Impedance (Z) | 8Ω |
| Resonant frequency (fs) | 56Hz |
| Max. frequency range | f3-3,000Hz |
| Music power | 300WMAX |
| Power rating (P) | 150WRMS |
| SPL (1W/m) | 93dB |
| Suspension compl. (Cms) | 0.35mm/N |
| Moving mass (Mms) | 22.8g |
| Mech. Q factor (Qms) | 1.52 |
| Electr. Q factor (Qes) | 0.41 |
| Total Q factor (Qts) | 0.32 |
| Equivalent volume (Vas) | 22 l |
| DC resistance (Re) | 7.2Ω |
| Force factor (BxL) | 11.96 |
| Voice coil induct. (Le) | 2.0mH |
| Voice coil diameter | dia 50mm |
| Voice coil former | aluminium |
| Linear excursion (XMAX) | ±6mm |
| Eff. cone area (Sd) | 213cm2 |
| Magnet weight | 850g |
| Weight | 1.9kg |
