Sarabec LA240 TV Loop Amplifier
Code: 91SLA240
Quantity Pricing
Choose quantity
Order now for next working day dispatch.
Description
The LA240 is easy to set up and operate and offers great sound
quality coupled with stylish design. It allows hearing aid
wearers with a loop program to move around the room freely
without restrictions or the need to wear a receiver.
It's compact profile allows it to stand vertically or horizontally, making it less intrusive in your home. The amplifier is supplied as a complete, easy to install. mains powered home loop system. Most commonly used with the TV, this loop system can also be connected to a hi-fi system for listening to the radio or to music. It comes with 40m of loop cable, which is placed around the room that you want to listen in, usually just above the skirting board, and cut down to size. We recommend that it is secured down using the cable clips for safety reasons. This is not difficult to do and is easy for anyone with average DIY skills.
- Adjustable rotary volume and tone controls
- Loop current indicator
- Sound source selection on front panel
- 2 electret 3.5mm microphone sockets*
- Microphone priority facility
- Automatic gain control (AGC)
- 2 analogue phono input sockets
- Digital audio Optical/Coaxial input
- 3.5mm headphone socket
- DC Power supply, can be used with 12-24AV external
supplies
The system can be used with digital audio, coaxial or optical, or analogue phono connections. A microphone can also be used where necessary. An automatic gain control keeps the volume of the TV constant despite program variations.There is also a headphone socket to allow easy testing or listening, even if you don't have a hearing aid.
Details
Power Supply:
- 18V 1.5A Power Supply
- 12-24V DC 2A External Supply
Controls:
- Rotary Volume Control
- Rotary Tone control
- On/Off power switch
- Source selector switches
- Priority switch
Input connections:
- Digital Audio TOSlink/Coaxial
- 2 x Microphone inputs. 3.5mm mono jack plug. DC powered 5V for electret microphones
- 2x Aux In Left/Right line inputs. Phono/RCA sockets. For direct connection to a TV sound output or or other suitable audio source socket.
Output connections:
- Push grip connectors for loop cable or loop pad (Labelled: Loop Cable). Loop will give full output with loop resistance between 0.5 and 1.5 Ohms.
- 3.5mm stereo jack for headphones (Phones) 8-60 Ohms
Loop output:
- 3.0A output current @ 100-5KHz. Meets BS EN60118-4:2006 for a loop not exceeding 6.5m (20ft) in width . Suitable for areas up to 70m2
Loop Cable:
- Single turn loop cable. System supplied with 40m (130ft) 24/0.2mm (0.75mm2) single core PVC insulated cable. Min cable length 11m = 0.5 Ohms
Indicators:
- Red & Blue LED's
